Project #14: Components – SparkFun XBee Explorer Regulated – Mk05
——
——
——
——
SparkFun XBee Explorer Regulated
SparkFun Item: WRL-11373
The SparkFun XBee Explorer Regulated takes care of the 3.3V regulation, signal conditioning, and basic activity indicators. It translates the 5V serial signals to 3.3V so that you can connect a 5V (down to 3.3V) system to any XBee module. The board was conveniently designed to mate directly with the SparkFun Arduino Pro series of boards for wireless bootloading and USB based configuration.
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – Unmanned Vehicles 1f – Mk10
——
——
——
——
——
——
——
——
——
Transmitter
DL2002Mk07
1 x Arduino UNO – R3
1 x ProtoScrewShield
1 x Adafruit RGB LCD Shield 16×2 Character Display
1 x XBee S1
1 x SparkFun XBee Explorer Regulated
1 x Slide Pot (Small)
1 x Knob
1 x Acrylic Blue 5.75in x 3.75in x 1/8in
24 x Screw – 4-40
12 x Standoff – Metal 4-40 – 3/8″
7 x Wire Solid Core – 22 AWG
1 x SparkFun XBee Explorer USB
1 x DIGI XCTU Software
1 x SparkFun Cerberus USB Cable
Arduino UNO
TX0 – Digital 1
RX0 – Digital 0
LP1 – Analog A0
VIN – +5V
GND – GND
XBee S1: Transmitter
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 40717A1F
CE Coordinator: Coordinator
BD: 9600
DL2002Mk07p.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1f - Mk10 // 02-07 // DL2002Mk01p.ino 12-10 // Arduino UNO - R3 // ProtoScrewShield // Adafruit RGB LCD Shield 16×2 Character Display // EEPROM with Unique ID // Transmitter // XBee S1 // Stepper // Slide Pot (Small) // Knob // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Adafruit RGB LCD Shield #include <Adafruit_RGBLCDShield.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // Communication unsigned long dTime = 50; // Slide Pot (Small) int iSP1 = A0; // Select the input pin for the slide pot int iValue = 0; // Variable to store the value // The current address in the EEPROM (i.e. which byte we're going to read to next) // Version String sver = "12-10.p"; // Unit ID Information String uid = ""; void loop() { // Clear RGBLCDShield.clear(); // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // Forward isSwitch1(); break; case 2: // Reverse isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // Stop isSwitch5(); break; default: // Stop yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // Forward RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // Reverse RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // Right RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // Left RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // Stop RGBLCDShield.setBacklight(RED); } } // Read the value iValue = analogRead( iSP1 ); // Process Message isProcessMessage(); delay( dTime ); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { // Loop through serial buffer while ( Serial.available() ) { // Print = "<" + yy + "|" + sver + "|" + iValue + "*" Serial.print( '<' ); Serial.print( yy ); Serial.print( '|' ); Serial.print( iValue ); Serial.println( '*' ); } }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ yy = 1; // Stepper // Forward RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Forward"); } // Switch 2 void isSwitch2(){ yy = 2; // Stepper // Reverse RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Reverse"); } // Switch 3 void isSwitch3(){ yy = 3; // Stepper // Right RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Right"); } // Switch 4 void isSwitch4(){ yy = 4; // Stepper // Left RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Left"); } // Switch 5 void isSwitch5(){ yy = 5; // Stepper // Stop RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); }
setup.ino
// Setup void setup() { // Open serial port at 9600 baud Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // Robotics delay(5000); // Clear RGBLCDShield.clear(); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Version: "); // Version RGBLCDShield.print( sver ); // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("UID: "); // Unit ID Information RGBLCDShield.print( uid ); delay(5000); // Clear RGBLCDShield.clear(); }
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #14: Components – Pan/Tilt Bracket Kit – Mk04
——
——
——
SparkFun Item: ROB-14391
This is an easy-to-assemble pan/tilt bracket kit that utilizes servos to move on two axes fit for camera and helping-hand applications. Everything is included to get this kit assembled, even the servos.
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – Unmanned Vehicles 1e – Mk09
——
——
——
——
——
——
DL2002Mk05
1 x Arduino UNO – R3
1 x Arduino UNO – SparkFun RedBoard
1 x ProtoScrewShield
1 x Adafruit RGB LCD Shield 16×2 Character Display
2 x XBee S1
1 x SparkFun XBee Explorer Regulated
1 x Breakout Board for XBee Module
2 x EasyDriver
2 x Small Stepper
1 x Adafruit PowerBoost 500 Shield
1 x Lithium Ion Battery – 2Ah
1 x LED Green
1 x Slide Pot (Small)
1 x Knob
7 x Jumper Wires 3″ M/M
16 x Jumper Wires 6″ M/M
1 x Full-Size Breadboard
1 x SparkFun XBee Explorer USB
1 x DIGI XCTU Software
1 x SparkFun USB Mini-B Cable
1 x SparkFun Cerberus USB Cable
Arduino UNO
TX0 – Digital 1
RX0 – Digital 0
LP1 – Analog A0
VIN – +5V
GND – GND
XBee S1: Transmitter
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 40717A1F
CE Coordinator: Coordinator
BD: 9600
DL2002Mk05p.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1d - Mk09 // 02-05 // DL2002Mk01p.ino 12-09 // Arduino UNO - R3 // ProtoScrewShield // Adafruit RGB LCD Shield 16×2 Character Display // EEPROM with Unique ID // Transmitter // XBee S1 // Stepper // Slide Pot (Small) // Knob // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Adafruit RGB LCD Shield #include <Adafruit_RGBLCDShield.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // Communication unsigned long dTime = 50; // Slide Pot (Small) int iSP1 = A0; // Select the input pin for the slide pot int iValue = 0; // Variable to store the value // The current address in the EEPROM (i.e. which byte we're going to read to next) // Version String sver = "12-9.p"; // Unit ID Information String uid = ""; void loop() { // Clear RGBLCDShield.clear(); // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // Up isSwitch1(); break; case 2: // Down isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // Stop isSwitch5(); break; default: // Stop yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // Up RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // Down RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // Right RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // Left RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // Stop RGBLCDShield.setBacklight(RED); } } // Read the value iValue = analogRead( iSP1 ); // Process Message isProcessMessage(); delay( dTime ); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { // String msg = ""; /// Loop through serial buffer one byte at a time until you reach * which will be end of message //while ( Serial.available() ) // { // Print => XBEE + Unit ID + Version + * // msg = "XBEE|" + uid + "|" + sver + "|" + yy + "|*"; Serial.print( '<' ); Serial.print( yy ); Serial.print( '|' ); Serial.print( iValue ); Serial.println( '*' ); // } }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ yy = 1; // Stepper // Up RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Up"); } // Switch 2 void isSwitch2(){ yy = 2; // Stepper // Down RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Down"); } // Switch 3 void isSwitch3(){ yy = 3; // Stepper // Right RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Right"); } // Switch 4 void isSwitch4(){ yy = 4; // Stepper // Left RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Left"); } // Switch 5 void isSwitch5(){ yy = 5; // Stepper // Stop RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); }
setup.ino
// Setup void setup() { // Open serial port at 9600 baud Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // Robotics // Serial // Serial.println( "Don Luc Electronics"); // Serial.println( "Robotics"); delay(5000); // Clear RGBLCDShield.clear(); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Version: "); // Version RGBLCDShield.print( sver ); // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("UID: "); // Unit ID Information RGBLCDShield.print( uid ); // Serial // Serial.print( "Software Version Information: "); // Serial.println( sver ); // Serial.print( "Unit ID Information: "); // Serial.println( uid ); delay(5000); // Clear RGBLCDShield.clear(); }
Arduino UNO – SparkFun RedBoard
LEG – Digital 6
SP1 – Digital 3
DI1 – Digital 2
SP2 – Digital 5
DI2 – Digital 4
TX0 – Digital 1
RX0 – Digital 0
VIN – +5V
GND – GND
XBee S1: Receiver
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 4076E2C5
CE Coordinator: End Device
BD: 9600
DL2002Mk05Rp.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1e - Mk09 // 02-05 // DL2002Mk05Rp.ino 12-09 // Arduino UNO - SparkFun RedBoard // EEPROM with Unique ID // Receiver // Breakout Board for XBee Module // XBee S1 // 2 x EasyDriver // 2 x Small Stepper // Adafruit PowerBoost 500 Shield // Lithium Ion Battery - 2Ah // LED Green // delayMicroseconds // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Momentary Button int yy = ""; // 2 x EasyDriver - 2 x Stepper int dirPinR = 2; // EasyDriver Right int stepPinR = 3; // stepPin Right int dirPinL = 4; // EasyDriver Left int stepPinL = 5; // stepPin Left int i = 0; // LED Green int iLEDGreen = 6; // Process Message bool bStart = false; // Start bool bEnd = false; // End int incb = 0; // Variable to store the incoming byte String msg = ""; // Message String zzz = ""; byte in = 0; // Index int x = 0; // delayMicroseconds int dMicro = 0; // Software Version Information String sver = "12-09"; // Unit ID information String uid = ""; void loop() { // Check for serial messages if ( Serial.available() ) { isProcessMessage(); } // Switch isSwitch(); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { // Loop through serial buffer one byte at a time until you reach * which will be end of message while ( Serial.available() ) { // Read the incoming byte: incb = Serial.read(); // Start the message when the '<' symbol is received if(incb == '<') { bStart = true; in = 0; msg = ""; } // End the message when the '*' symbol is received else if(incb == '*') { bEnd = true; x = msg.length(); msg.remove( x , 1); break; // Done reading } // Read the message else { if(in < 8) // Make sure there is room { msg = msg + char(incb); in++; } } } if( bStart && bEnd) { // Stepper zzz = msg.charAt( 0 ); yy = zzz.toInt(); msg.remove( 0 , 2); // delayMicroseconds dMicro = msg.toInt() + 300; in = 0; zzz = ""; msg = ""; bStart = false; bEnd = false; } }
getStepper.ino
// Stepper // isStepperSetup void isStepperSetup() { // 2 x EasyDriver pinMode(dirPinR, OUTPUT); pinMode(stepPinR, OUTPUT); pinMode(dirPinL, OUTPUT); pinMode(stepPinL, OUTPUT); } // isStepper1 void isStepper1(){ // 2 x EasyDriver - Up digitalWrite(dirPinR, LOW); // Set the direction. digitalWrite(dirPinL, LOW); // Set the direction. digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. } // isStepper2 void isStepper2(){ // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. digitalWrite(dirPinL, HIGH); // Set the direction. digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. } // Switch 3 void isStepper3(){ // Right // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. digitalWrite(dirPinL, HIGH); // Set the direction. delay(5); digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. } // Switch 4 void isStepper4(){ // Left // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. digitalWrite(dirPinL, LOW); // Set the direction. digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(dMicro); // This delay time is close to top speed. } // isStepperStop void isStepperStop() { // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the }
getSwitch.ino
// Switch // isSwitch void isSwitch(){ switch ( yy ) { case 1: // Stepper 1 - Up isStepper1(); break; case 2: // Stepper 2 - Back isStepper2(); break; case 3: // Stepper 3 - Right isStepper3(); break; case 4: // Stepper 4 - Left isStepper4(); break; case 5: // Stepper Stop isStepperStop(); break; default: // Stepper Stop isStepperStop(); } }
setup.ino
// Setup void setup() { // Open the serial port at 9600 bps: Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // 2 x EasyDriver isStepperSetup(); // LED Green pinMode(iLEDGreen, OUTPUT); digitalWrite(iLEDGreen, HIGH); }
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #14: Components – Slide Pot (Small) – Knob – Mk03
——
——
——
——
Slide Pot – Small (10k Linear Taper)
SparkFun Item: COM-11620
A simple slide potentiometer can go a long way. Rated at 10KOhm and 0.1W. Comes with solder tab connections. The pot has an overall travel of 20mm and has two mounting holes on top.
Slide Potentiometer Knob
SparkFun Item: COM-14889
This is a simple knob that connects to the small and medium sized linear slide potentiometers. Each knob uses friction to secure itself to fit onto the slide pot. Once attached, this small knob provides you with an easier to use potentiometer for your project.
A printed circuit board (PCB) mechanically supports and electrically connects electrical or electronic components.
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – Unmanned Vehicles 1d – Mk08
——
——
——
——
——
——
DL2002Mk03
1 x Arduino UNO – R3
1 x Arduino UNO – SparkFun RedBoard
1 x ProtoScrewShield
1 x Adafruit RGB LCD Shield 16×2 Character Display
2 x XBee S1
1 x SparkFun XBee Explorer Regulated
1 x Breakout Board for XBee Module
2 x EasyDriver
2 x Small Stepper
1 x Adafruit PowerBoost 500 Shield
1 x Lithium Ion Battery – 2Ah
1 x LED Green
7 x Jumper Wires 3″ M/M
13 x Jumper Wires 6″ M/M
1 x Full-Size Breadboard
1 x SparkFun XBee Explorer USB
1 x DIGI XCTU Software
1 x SparkFun USB Mini-B Cable
1 x SparkFun Cerberus USB Cable
Arduino UNO
TX0 – Digital 1
RX0 – Digital 0
VIN – +5V
GND – GND
XBee S1: Transmitter
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 40717A1F
CE Coordinator: Coordinator
BD: 9600
DL2002Mk03p.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1d - Mk08 // 02-03 // DL2002Mk01p.ino 12-08 // Arduino UNO - R3 // ProtoScrewShield // Adafruit RGB LCD Shield 16×2 Character Display // EEPROM with Unique ID // Transmitter // XBee S1 // Stepper // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Adafruit RGB LCD Shield #include <Adafruit_RGBLCDShield.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // Communication unsigned long dTime = 50; // The current address in the EEPROM (i.e. which byte we're going to read to next) // Version String sver = "12-7.p"; // Unit ID Information String uid = ""; void loop() { // Clear RGBLCDShield.clear(); // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // Up isSwitch1(); break; case 2: // Down isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // Stop isSwitch5(); break; default: // Stop yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // Up RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // Down RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // Right RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // Left RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // Stop RGBLCDShield.setBacklight(RED); } } // Process Message isProcessMessage(); delay( dTime ); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { // String msg = ""; /// Loop through serial buffer one byte at a time until you reach * which will be end of message //while ( Serial.available() ) // { // Print => XBEE + Unit ID + Version + * // msg = "XBEE|" + uid + "|" + sver + "|" + yy + "|*"; Serial.print( '<' ); Serial.print( yy ); Serial.println( '*' ); // } }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ yy = 1; // Stepper // Up RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Up"); } // Switch 2 void isSwitch2(){ yy = 2; // Stepper // Down RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Down"); } // Switch 3 void isSwitch3(){ yy = 3; // Stepper // Right RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Right"); } // Switch 4 void isSwitch4(){ yy = 4; // Stepper // Left RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Left"); } // Switch 5 void isSwitch5(){ yy = 5; // Stepper // Stop RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); }
setup.ino
// Setup void setup() { // Open serial port at 9600 baud Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // Robotics // Serial // Serial.println( "Don Luc Electronics"); // Serial.println( "Robotics"); delay(5000); // Clear RGBLCDShield.clear(); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Version: "); // Version RGBLCDShield.print( sver ); // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("UID: "); // Unit ID Information RGBLCDShield.print( uid ); // Serial // Serial.print( "Software Version Information: "); // Serial.println( sver ); // Serial.print( "Unit ID Information: "); // Serial.println( uid ); delay(5000); // Clear RGBLCDShield.clear(); }
Arduino UNO – SparkFun RedBoard
LEG – Digital 6
SP1 – Digital 3
DI1 – Digital 2
SP2 – Digital 5
DI2 – Digital 4
TX0 – Digital 1
RX0 – Digital 0
VIN – +3.3V
GND – GND
XBee S1: Receiver
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 4076E2C5
CE Coordinator: End Device
BD: 9600
DL2002Mk03Rp.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1d - Mk08 // 02-03 // DL2002Mk01Rp.ino 12-08 // Arduino UNO - SparkFun RedBoard // EEPROM with Unique ID // Receiver // Breakout Board for XBee Module // XBee S1 // 2 x EasyDriver // 2 x Small Stepper // Adafruit PowerBoost 500 Shield // Lithium Ion Battery - 2Ah // LED Green // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Momentary Button int yy = ""; // 2 x EasyDriver - 2 x Stepper int dirPinR = 2; // EasyDriver Right int stepPinR = 3; // stepPin Right int dirPinL = 4; // EasyDriver Left int stepPinL = 5; // stepPin Left int i = 0; // LED Green int iLEDGreen = 6; // Software Version Information String sver = "12-08"; // Unit ID information String uid = ""; void loop() { // Check for serial messages if ( Serial.available() ) { isProcessMessage(); } // Switch isSwitch(); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { int incb = 0; String msg = ""; String zzz = ""; // Loop through serial buffer one byte at a time until you reach * which will be end of message while ( Serial.available() ) { // Read the incoming byte: incb = Serial.read(); // Add character to string msg = msg + char(incb); // Check if receive character is the end of message * if ( incb == 42 ) { // Serial.println(msg); zzz = msg.charAt( 1 ); // Serial.println(zzz); yy = zzz.toInt(); // Serial.println( yy ); } } }
getStepper.ino
// Stepper // isStepperSetup void isStepperSetup() { // 2 x EasyDriver pinMode(dirPinR, OUTPUT); pinMode(stepPinR, OUTPUT); pinMode(dirPinL, OUTPUT); pinMode(stepPinL, OUTPUT); } // isStepper1 void isStepper1(){ // 2 x EasyDriver - Up digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // isStepper2 void isStepper2(){ // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. delay(5); digitalWrite(dirPinL, HIGH); // Set the direction. delay(5); for (i = 0; i<1000; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // Switch 3 void isStepper3(){ // Right // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, HIGH); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // Switch 4 void isStepper4(){ // Left // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // isStepperStop void isStepperStop() { // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the }
getSwitch.ino
// Switch // isSwitch void isSwitch(){ switch ( yy ) { case 1: // Stepper 1 - Up isStepper1(); break; case 2: // Stepper 2 - Back isStepper2(); break; case 3: // Stepper 3 - Right isStepper3(); break; case 4: // Stepper 4 - Left isStepper4(); break; case 5: // Stepper Stop isStepperStop(); break; default: // Stepper Stop isStepperStop(); } }
setup.ino
// Setup void setup() { // Open the serial port at 9600 bps: Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Serial // Serial.print( "Software Version Information: "); // Serial.println( sver ); // Serial.print( "Unit ID Information: "); // Serial.println( uid ); // delay(5000); // 2 x EasyDriver isStepperSetup(); // LED Green pinMode(iLEDGreen, OUTPUT); digitalWrite(iLEDGreen, HIGH); }
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – Unmanned Vehicles 1c – Mk07
——
——
——
——
——
DL2002Mk01
1 x Arduino UNO – R3
1 x Arduino UNO – SparkFun RedBoard
1 x ProtoScrewShield
1 x Adafruit RGB LCD Shield 16×2 Character Display
2 x XBee S1
1 x SparkFun XBee Explorer Regulated
1 x Breakout Board for XBee Module
2 x EasyDriver
2 x Small Stepper
6 x Jumper Wires 3″ M/M
12 x Jumper Wires 6″ M/M
1 x Full-Size Breadboard
1 x SparkFun XBee Explorer USB
1 x DIGI XCTU Software
1 x SparkFun USB Mini-B Cable
1 x SparkFun Cerberus USB Cable
Arduino UNO
TX0 – Digital 1
RX0 – Digital 0
VIN – +5V
GND – GND
XBee S1: Transmitter
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 40717A1F
CE Coordinator: Coordinator
BD: 9600
DL2002Mk01p.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1c - Mk07 // 02-01 // DL2002Mk01p.ino 12-07 // Arduino UNO - R3 // ProtoScrewShield // Adafruit RGB LCD Shield 16×2 Character Display // EEPROM with Unique ID // Transmitter // XBee S1 // Stepper // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Adafruit RGB LCD Shield #include <Adafruit_RGBLCDShield.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // Communication unsigned long dTime = 50; // The current address in the EEPROM (i.e. which byte we're going to read to next) // Version String sver = "12-7.p"; // Unit ID Information String uid = ""; void loop() { // Clear RGBLCDShield.clear(); // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // Up isSwitch1(); break; case 2: // Down isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // Stop isSwitch5(); break; default: // Stop yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // Up RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // Down RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // Right RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // Left RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // Stop RGBLCDShield.setBacklight(RED); } } // Process Message isProcessMessage(); delay( dTime ); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { // String msg = ""; /// Loop through serial buffer one byte at a time until you reach * which will be end of message //while ( Serial.available() ) // { // Print => XBEE + Unit ID + Version + * // msg = "XBEE|" + uid + "|" + sver + "|" + yy + "|*"; Serial.print( '<' ); Serial.print( yy ); Serial.println( '*' ); // } }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ yy = 1; // Stepper // Up RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Up"); } // Switch 2 void isSwitch2(){ yy = 2; // Stepper // Down RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Down"); } // Switch 3 void isSwitch3(){ yy = 3; // Stepper // Right RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Right"); } // Switch 4 void isSwitch4(){ yy = 4; // Stepper // Left RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Left"); } // Switch 5 void isSwitch5(){ yy = 5; // Stepper // Stop RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); }
setup.ino
// Setup void setup() { // Open serial port at 9600 baud Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // Robotics // Serial // Serial.println( "Don Luc Electronics"); // Serial.println( "Robotics"); delay(5000); // Clear RGBLCDShield.clear(); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Version: "); // Version RGBLCDShield.print( sver ); // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("UID: "); // Unit ID Information RGBLCDShield.print( uid ); // Serial // Serial.print( "Software Version Information: "); // Serial.println( sver ); // Serial.print( "Unit ID Information: "); // Serial.println( uid ); delay(5000); // Clear RGBLCDShield.clear(); }
Arduino UNO – SparkFun RedBoard
SP1 – Digital 3
DI1 – Digital 2
SP2 – Digital 5
DI2 – Digital 4
TX0 – Digital 1
RX0 – Digital 0
VIN – +3.3V
GND – GND
XBee S1: Receiver
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 4076E2C5
CE Coordinator: End Device
BD: 9600
DL2002Mk01Rp.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1c - Mk07 // 02-01 // DL2002Mk01Rp.ino 12-07 // Arduino UNO - SparkFun RedBoard // EEPROM with Unique ID // Receiver // Breakout Board for XBee Module // XBee S1 // 2 x EasyDriver // 2 x Small Stepper // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Momentary Button int yy = ""; // 2 x EasyDriver - 2 x Stepper int dirPinR = 2; // EasyDriver Right int stepPinR = 3; // stepPin Right int dirPinL = 4; // EasyDriver Left int stepPinL = 5; // stepPin Left int i = 0; // Software Version Information String sver = "12-07"; // Unit ID information String uid = ""; void loop() { // Check for serial messages if ( Serial.available() ) { isProcessMessage(); } // Switch isSwitch(); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { int incb = 0; String msg = ""; String zzz = ""; // Loop through serial buffer one byte at a time until you reach * which will be end of message while ( Serial.available() ) { // Read the incoming byte: incb = Serial.read(); // Add character to string msg = msg + char(incb); // Check if receive character is the end of message * if ( incb == 42 ) { // Serial.println(msg); zzz = msg.charAt( 1 ); // Serial.println(zzz); yy = zzz.toInt(); // Serial.println( yy ); } } }
getStepper.ino
// Stepper // isStepperSetup void isStepperSetup() { // 2 x EasyDriver pinMode(dirPinR, OUTPUT); pinMode(stepPinR, OUTPUT); pinMode(dirPinL, OUTPUT); pinMode(stepPinL, OUTPUT); } // isStepper1 void isStepper1(){ // 2 x EasyDriver - Up digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // isStepper2 void isStepper2(){ // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. delay(5); digitalWrite(dirPinL, HIGH); // Set the direction. delay(5); for (i = 0; i<1000; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // Switch 3 void isStepper3(){ // Right // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, HIGH); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // Switch 4 void isStepper4(){ // Left // 2 x EasyDriver digitalWrite(dirPinR, HIGH); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(300); // This delay time is close to top speed. } } // isStepperStop void isStepperStop() { // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(5); digitalWrite(dirPinL, LOW); // Set the direction. delay(5); digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the }
getSwitch.ino
// Switch // isSwitch void isSwitch(){ switch ( yy ) { case 1: // Stepper 1 - Up isStepper1(); break; case 2: // Stepper 2 - Back isStepper2(); break; case 3: // Stepper 3 - Right isStepper3(); break; case 4: // Stepper 4 - Left isStepper4(); break; case 5: // Stepper Stop isStepperStop(); break; default: // Stepper Stop isStepperStop(); } }
setup.ino
// Setup void setup() { // Open the serial port at 9600 bps: Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Serial // Serial.print( "Software Version Information: "); // Serial.println( sver ); // Serial.print( "Unit ID Information: "); // Serial.println( uid ); // delay(5000); // 2 x EasyDriver isStepperSetup(); }
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #14: Components – Pololu 5V Step-Up Voltage Regulator – Mk01
——
——
——
Pololu Item: 2564
5V Step-Up Voltage Regulator U1V10F5
This tiny (0.35″×0.45″) U1V10F5 switching step-up (or boost) voltage regulator efficiently generates 5 V from input voltages as low as 0.5 V. Unlike most boost regulators, the U1V10F5 automatically switches to a linear down-regulation mode when the input voltage exceeds the output. The pins have a 0.1? spacing, making this board compatible with standard solderless breadboards and perfboards.
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – Unmanned Vehicles 1b – Mk06
——
——
——
——
——
XBee
Digi XBee is the brand name of a family of form factor compatible radio modules from Digi International. The first XBee radios were introduced under the MaxStream brand in 2005 and were based on the IEEE 802.15.4-2003 standard designed for point-to-point and star communications at over-the-air baud rates of 250 kbit/s.
Two models were initially introduced, a lower cost 1 mW XBee and the higher power 100 mW XBee-PRO. Since the initial introduction, a number of new XBee radios have been introduced and an ecosystem of wireless modules, gateways, adapters and software has evolved.
The XBee radios can all be used with the minimum number of connections — power (3.3 V), ground, data in and data out (UART), with other recommended lines being Reset and Sleep. Additionally, most XBee families have some other flow control, input/output (I/O), analog-to-digital converter (A/D) and indicator lines built in.
DL2001Mk02
1 x Arduino Fio
1 x Arduino UNO – R3
1 x ProtoScrewShield
1 x Adafruit RGB LCD Shield 16×2 Character Display
2 x XBee S1
1 x SparkFun XBee Explorer Regulated
1 x Lithium Ion Battery – 2.5Ah
1 x LED Red
1 x LED Green
1 x LED Bi-Colour
1 x LED Yellow
4 x Jumper Wires 3″ M/M
10 x Jumper Wires 6″ M/M
1 x Half-Size Breadboard
1 x SparkFun XBee Explorer USB
1 x DIGI XCTU Software
1 x SparkFun FTDI Basic Breakout – 3.3V
1 x SparkFun Cerberus USB Cable
Arduino UNO
TX0 – Digital 1
RX0 – Digital 0
VIN – +5V
GND – GND
XBee S1: Transmitter
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 40717A1F
CE Coordinator: Coordinator
BD: 9600
DL2001Mk02p.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1b - Mk06 // 01-02 // DL2001Mk01p.ino 12-06 // Arduino UNO - R3 // ProtoScrewShield // Adafruit RGB LCD Shield 16×2 Character Display // EEPROM with Unique ID // Transmitter // XBee S1 // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // Adafruit RGB LCD Shield #include <Adafruit_RGBLCDShield.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // Communication unsigned long dTime = 1000; // The current address in the EEPROM (i.e. which byte we're going to read to next) // Version String sver = "12-2.p"; // Unit ID Information String uid = ""; void loop() { // Clear RGBLCDShield.clear(); // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // LED Green isSwitch1(); break; case 2: // LED Bipolar (Green) isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // LED Red isSwitch5(); break; default: // LED Red yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // LED Green RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // LED Bipolar A RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // LED Bipolar B RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // LED Bipolar A B RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // LED Red RGBLCDShield.setBacklight(RED); } } // Process Message isProcessMessage(); delay( dTime ); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { //int incb = 0; String msg = ""; /// Loop through serial buffer one byte at a time until you reach * which will be end of message //while ( Serial.available() ) // { // Print => XBEE + Unit ID + Version + * msg = "XBEE|" + uid + "|" + sver + "|" + yy + "|*"; Serial.println( msg ); // } }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ yy = 1; isSwitchLEDStop(); // LED // turn LED on: RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Green"); } // Switch 2 void isSwitch2(){ yy = 2; isSwitchLEDStop(); // LED // turn LED on: RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Bi-Colour A"); } // Switch 3 void isSwitch3(){ yy = 3; isSwitchLEDStop(); // LED // turn LED on: RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Bi-Colour B"); } // Switch 4 void isSwitch4(){ yy = 4; isSwitchLEDStop(); // LED // turn LED on: RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Bi-Colour A B"); } // Switch 5 void isSwitch5(){ yy = 5; RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); //delay( 250 ); isSwitchLEDStop(); // LED // turn LED on: //digitalWrite(iLEDRed, HIGH); } void isSwitchLEDStop(){ //digitalWrite(iLEDRed, LOW); //digitalWrite(iLEDGreen, LOW); //digitalWrite(iLEDB1, LOW); //digitalWrite(iLEDB2, LOW); //digitalWrite(iLEDYellow, LOW); }
setup.ino
// Setup void setup() { //Open serial port at 9600 baud Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // Robotics // Serial Serial.println( "Don Luc Electronics"); Serial.println( "Robotics"); delay(5000); // Clear RGBLCDShield.clear(); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Version: "); // Version RGBLCDShield.print( sver ); // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("UID: "); // Unit ID Information RGBLCDShield.print( uid ); // Serial Serial.print( "Software Version Information: "); Serial.println( sver ); Serial.print( "Unit ID Information: "); Serial.println( uid ); delay(5000); // Clear RGBLCDShield.clear(); }
Arduino Fio
LER – Digital 13
LEG – Digital 12
LEA – Digital 11
LEB – Digital 10
LEY – Digital 9
TX0 – Digital 1
RX0 – Digital 0
VIN – +3.3V
GND – GND
XBee S1: Receiver
CH Channel: C
PAN Id: 3333
SH Serial Number: 13A200
SL Serial Number: 4076E2C5
CE Coordinator: End Device
BD: 9600
DL2001Mk02Rp.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - Unmanned Vehicles 1b - Mk06 // 01-02 // DL2001Mk02Rp.ino 12-06 // Arduino Fio // SparkFun FTDI Basic Breakout - 3.3V // EEPROM with Unique ID // LED Red // LED Green // LED Bi-Colour // LED Yellow // Lithium Ion Battery - 2.5Ah // Receiver // XBee S1 // Include the library code: // EEPROM library to read and write EEPROM with unique ID for unit #include <EEPROM.h> // LED Red int iLEDRed = 13; // LED Green int iLEDGreen = 12; // LED Bi-Colour int iLEDBiCoA = 11; int iLEDBiCoB = 10; // LED Yellow int iLEDYellow = 9; // Momentary Button int yy = ""; // Software Version Information String sver = "12-02"; // Unit ID information String uid = "DR001"; void loop() { // Check for serial messages if ( Serial.available() ) { isProcessMessage(); } // Switch isSwitch(); }
getEEPROM.ino
// EEPROM // isUID void isUID() { // Is Unit ID uid = ""; for (int x = 0; x < 5; x++) { uid = uid + char(EEPROM.read(x)); } }
getProcessMessage.ino
// ProcessMessage // isProcessMessage void isProcessMessage() { int incb = 0; String msg = ""; String zzz = ""; // Loop through serial buffer one byte at a time until you reach * which will be end of message while ( Serial.available() ) { // Read the incoming byte: incb = Serial.read(); // Add character to string msg = msg + char(incb); // Check if receive character is the end of message * if ( incb == 42 ) { Serial.println(msg); zzz = msg.charAt( 18 ); Serial.println(zzz); yy = zzz.toInt(); Serial.println( yy ); } } }
getSwitch.ino
// Switch // isSwitch void isSwitch(){ switch ( yy ) { case 1: // LED Green sLEDStop(); digitalWrite(iLEDGreen, HIGH); delay( 1000 ); break; case 2: // LED Bi-Colour A sLEDStop(); digitalWrite(iLEDBiCoA, HIGH); delay( 1000 ); break; case 3: // LED Bi-Colour B sLEDStop(); digitalWrite(iLEDBiCoB, HIGH); delay( 1000 ); break; case 4: // LED Bi-Colour A B sLEDStop(); digitalWrite(iLEDBiCoA, HIGH); digitalWrite(iLEDBiCoB, HIGH); delay( 1000 ); break; case 5: // LED Red sLEDStop(); digitalWrite(iLEDRed, HIGH); delay( 1000 ); break; default: // LED Red sLEDStop(); digitalWrite(iLEDRed, HIGH); delay( 1000 ); } } // LED Stop void sLEDStop(){ digitalWrite(iLEDRed, LOW); digitalWrite(iLEDGreen, LOW); digitalWrite(iLEDBiCoA, LOW); digitalWrite(iLEDBiCoB, LOW); }
setup.ino
// Setup void setup() { // Open the serial port at 9600 bps: Serial.begin( 9600 ); // Pause delay(5); // EEPROM Unit ID isUID(); // Pause delay(5); // Serial Serial.print( "Software Version Information: "); Serial.println( sver ); Serial.print( "Unit ID Information: "); Serial.println( uid ); delay(5000); // LED => OUTPUT pinMode(iLEDRed, OUTPUT); pinMode(iLEDGreen, OUTPUT); pinMode(iLEDBiCoA, OUTPUT); pinMode(iLEDBiCoB, OUTPUT); pinMode(iLEDYellow, OUTPUT); // LED Yellow digitalWrite(iLEDYellow, HIGH); }
Follow Us
J. Luc Paquin – Curriculum Vitae
https://www.donluc.com/DLHackster/LucPaquinCVEngMk2020a.pdf
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
Project #12: Robotics – 5-Way Switch – Mk04
——
——
——
——
——
——
——
SparkFun 5-Way Tactile Switch Breakout
This 5-way tactile switch (up, down, left, right, and center click) allows for joystick-like control in a very small package.
DL1912Mk03
1 x Adafruit RGB LCD Shield 16×2 Character Display
1 x Arduino UNO – R3
1 x ProtoScrewShield
2 x EasyDriver – Stepper Motor Driver
1 x Small Stepper Motor
1 x Pololu Mounting
1 x Symbol Stepper Motor
2 x RC Servo Motor
2 x Potentiometer 1M Ohm
2 x Knob
2 x LED Red
1 x Rocker Switches
1 x Laser Red
1 x SparkFun 5-Way Tactile Switch Breakout
1 x LED Green
1 x LED Bi-Colour
1 x LED Yellow
17 x Jumper Wires 3″ M/M
31 x Jumper Wires 6″ M/M
4 x Half-Size Breadboard
Arduino UNO
SP1 – Digital 3
DI1 – Digital 2
SP2 – Digital 5
DI2 – Digital 4
SV1 – Digital 6
PO1 – Analog A0
SV2 – Digital 7
PO2 – Analog A1
VIN – +5V
GND – GND
DL1912Mk03.ino
// ***** Don Luc Electronics © ***** // Software Version Information // Project #12: Robotics - 5-Way Switch - Mk04 // 12-03 // DL1912Mk02p.ino 12-04 // Arduino UNO // Screw Shield // Adafruit RGB LCD Shield // 1 x Small Stepper Motor // 1 x Symbol Stepper Motor // 2 x EasyDriver // 2 x RC Servo Motor // 2 x Potentiometer // 2 x LED Red // 1 x Rocker Switches // 1 x Laser Red // 1 x SparkFun 5-Way Tactile Switch Breakout // 1 x LED Green // 1 x LED Bi-Colour // 1 x LED Yellow // include the library code: #include <Adafruit_RGBLCDShield.h> #include <Servo.h> // Adafruit RGB LCD Shield Adafruit_RGBLCDShield RGBLCDShield = Adafruit_RGBLCDShield(); // These #defines make it easy to set the backlight color #define OFF 0x0 #define RED 0x1 #define YELLOW 0x3 #define GREEN 0x2 #define TEAL 0x6 #define BLUE 0x4 #define VIOLET 0x5 #define WHITE 0x7 // Momentary Button int yy = 0; uint8_t momentaryButton = 0; // 2 x EasyDriver int dirPinR = 2; // EasyDriver Right int stepPinR = 3; // stepPin Right int dirPinL = 4; // EasyDriver Left int stepPinL = 5; // stepPin Left int i = 0; // 2 x RC Servo Motor // 2 x Potentiometer Servo isRCServo1; // Create servo object to control a RCServo1 int servo1 = 6; // Servo 1 int iPot1 = A0; // Analog Potentiometer 1 int iVal1; // Variable - Analog Potentiometer 1 Servo isRCServo2; // Create servo object to control a RCServo2 int servo2 = 7; // Servo 2 int iPot2 = A1; // Analog Potentiometer 2 int iVal2; // Variable - Analog Potentiometer 2 void loop() { // Clear RGBLCDShield.clear(); // Momentary Button momentaryButton = RGBLCDShield.readButtons(); switch ( yy ) { case 1: // Up isSwitch1(); break; case 2: // Down isSwitch2(); break; case 3: // Right isSwitch3(); break; case 4: // Left isSwitch4(); break; case 5: // Stop isSwitch5(); break; default: // Stop yy = 5; RGBLCDShield.setBacklight(RED); isSwitch5(); } if ( momentaryButton ) { if ( momentaryButton & BUTTON_UP ) { yy = 1; // Up RGBLCDShield.setBacklight(GREEN); } if ( momentaryButton & BUTTON_DOWN ) { yy = 2; // Down RGBLCDShield.setBacklight(VIOLET); } if ( momentaryButton & BUTTON_LEFT ) { yy = 3; // Right RGBLCDShield.setBacklight(TEAL); } if ( momentaryButton & BUTTON_RIGHT ) { yy = 4; // Left RGBLCDShield.setBacklight(YELLOW); } if ( momentaryButton & BUTTON_SELECT ) { yy = 5; // Stop RGBLCDShield.setBacklight(RED); } } }
getServo.ino
// Servo // isServoSetup void isServoSetup() { // 2 x RC Servo Motor isRCServo1.attach( servo1 ); isRCServo2.attach( servo2 ); } // isServo1 void isServo1() { // EasyDriver isStepperStop(); // Potentiometer RC Servo Motor 1 iVal1 = analogRead( iPot1 ); // Reads the value of the iPot1 (Value between 0 and 1023) iVal1 = map(iVal1, 0, 1023, 0, 180); // Scale it to use it with the isRCServo1 (Value between 0 and 180) isRCServo1.write( iVal1 ); // isRCServo1 sets the servo position according to the scaled value delay(15); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("RC Servo 1"); // RC Servo 1 // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print( iVal1 ); // Reads the value iVal1 delay(500); } // isServo2 void isServo2() { // EasyDriver isStepperStop(); // Potentiometer RC Servo Motor 1 iVal2 = analogRead( iPot2 ); // Reads the value of the iPot2 (Value between 0 and 1023) iVal2 = map(iVal2, 0, 1023, 0, 180); // Scale it to use it with the isRCServo2 (Value between 0 and 180) isRCServo2.write( iVal2 ); // isRCServo2 sets the servo position according to the scaled value delay(15); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("RC Servo 2"); // RC Servo 2 // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print( iVal2 ); // Reads the value iVal2 delay(500); }
getStepper.ino
// Stepper // isStepperSetup void isStepperSetup() { // 2 x EasyDriver pinMode(dirPinR, OUTPUT); pinMode(stepPinR, OUTPUT); pinMode(dirPinL, OUTPUT); pinMode(stepPinL, OUTPUT); } // isStepper1 void isStepper1(){ // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("EasyDriver"); // EasyDriver RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Small Stepper"); // Small Stepper delay(500); // EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(100); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinR, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(170); // This delay time is close to top speed. } } // isStepper2 void isStepper2(){ // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("EasyDriver"); // EasyDriver RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Symbol Stepper"); // Symbol Stepper delay(500); // EasyDriver digitalWrite(dirPinL, HIGH); // Set the direction. delay(100); for (i = 0; i<300; i++) // Iterate for 1000 microsteps. { digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, HIGH); // "Rising Edge" so the easydriver knows to when to step. delayMicroseconds(170); // This delay time is close to top speed. } } // isStepperStop void isStepperStop() { // 2 x EasyDriver digitalWrite(dirPinR, LOW); // Set the direction. delay(100); digitalWrite(dirPinL, LOW); // Set the direction. delay(100); digitalWrite(stepPinR, LOW); // This LOW to HIGH change is what creates the digitalWrite(stepPinL, LOW); // This LOW to HIGH change is what creates the }
getSwitch.ino
// Switch // Switch 1 void isSwitch1(){ // Small Stepper yy = 1; // EasyDriver isStepper1(); } // Switch 2 void isSwitch2(){ // Symbol Stepper yy = 2; // EasyDriver isStepper2(); } // Switch 3 void isSwitch3(){ // RC Servo Motor 1 yy = 3; // Potentiometer RC Servo Motor 1 isServo1(); } // Switch 4 void isSwitch4(){ // RC Servo Motor 2 yy = 4; // Potentiometer RC Servo Motor 2 isServo2(); } // Switch 5 void isSwitch5(){ // Stop yy = 5; // set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Robotics"); // Robotics RGBLCDShield.setCursor(0,1); RGBLCDShield.print("Stop"); delay( 500 ); // EasyDriver isStepperStop(); }
setup.ino
// Setup void setup() { // Adafruit RGB LCD Shield // Set up the LCD's number of columns and rows: RGBLCDShield.begin(16, 2); RGBLCDShield.setBacklight(GREEN); // Display // Set the cursor to column 0, line 0 RGBLCDShield.setCursor(0,0); RGBLCDShield.print("Don Luc Electron"); // Don luc Electron // Set the cursor to column 0, line 1 RGBLCDShield.setCursor(0, 1); RGBLCDShield.print("Robotics"); // EasyDriver delay(5000); // Clear RGBLCDShield.clear(); // 2 x EasyDriver isStepperSetup(); // 2 x RC Servo Motor isServoSetup(); }
Follow Us
Web: https://www.donluc.com/
Web: http://www.jlpconsultants.com/
Web: https://www.donluc.com/DLHackster/
Web: https://www.hackster.io/neosteam-labs
Web: http://neosteamlabs.com/
YouTube: https://www.youtube.com/channel/UC5eRjrGn1CqkkGfZy0jxEdA
Facebook: https://www.facebook.com/neosteam.labs.9/
Instagram: https://www.instagram.com/neosteamlabs/
Pinterest: https://www.pinterest.com/NeoSteamLabs/
Twitter: https://twitter.com/labs_steam
Etsy: https://www.etsy.com/shop/NeoSteamLabs
Don Luc
